IoT SuperServer SYS-112B-FWT
- 1U Rackmount IoT
- Supported CPUs Intel Xeon 6500 P-cores
- Intel Xeon 6700 E-cores
- Intel Xeon 6700 P-cores
- CPU Socket 1
-
Max Supported Memory
1 TB DDR5 ECC Supported
-
Power Supply
800 W Titanium Redundant
Key Applications
- Multi-Access Edge Computing
- Flex-RAN, Open-RAN vBBU
- Artificial Intelligence (AI) on Edge
- DU of 5G Application
- Satellite Communication
Key Features
- Single Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores
- 8 DIMMs; Up to 1TB ECC DDR5-6400 RDIMM
- 2x FHFL PCIe 5.0 x16
- 1x LP PCIe 5.0 x16
Request a quote today
Share your email below to express your interest, and a Nextron representative will reach out shortly with detailed information and a personalized quote for your selected product.
More Specifications
- Configurable Configurable by Request
- Cores up to 144
- TDP 350 W
- M.2 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110)
- PCI-e Default: 2 PCIe 5.0 x16 FHFL slots
- Dimensions 1.7" (44.5 mm) Height
- Dimensions 16.9" (429.3 mm) Depth
- Dimensions 17.2" (436.88 mm) Width
- Product Model SYS-112B-FWT
- LAN 2 RJ45 10GbE with Intel X550 RJ45 10GbE
- NVMe 2 NVMe / SATA
- USB 2 USB 3.2 Gen1 Type-A ports(rear)
- Video Output 1 VGA port VGA port
- DIMM Type RDIMM
- Chipset System on Chip
- On-board NVMe NVMe
- Operating Temperature 10°C ~ 35°C (50°F ~ 95°F)
