IoT SuperServer SYS-112D-40C-FN8P
- Form Factor 1U Rackmount
- Supported CPU Intel Xeon 6700 P-cores
- CPU Socket 1
-
Max Supported Memory
512 GB DDR5 ECC Supported
-
Power Supply
800 W Platinum Redundant
Key Applications
- Multi-Access Edge Computing
- Flex-RAN, Open-RAN vBBU
- Telco Edge
- Artificial Intelligence (AI) on Edge
- DU of 5G Application
- Satellite Communication
- vRAN / o-RAN
Key Features
- Intel® Xeon® 6 SoC 6716P-B up to 235W with air cooling
- Support for up to 1 single-width GPU accelerator card
- Up to 4 DIMMs supporting up to 512GB DDR5-6400 in 1DPC
- 8 SFP28 25GbE ports
- Up to 2 PCIe 5.0 x16 FHHL slots
- Up to 2 internal fixed 2.5" NVMe drive bays
- 2 Redundant 800W Platinum Level power supplies
- 1U Rackmount chassis with 15.7" (399mm) depth
Request a quote today
Share your email below to express your interest, and a Nextron representative will reach out shortly with detailed information and a personalized quote for your selected product.
More Specifications
- CPU Manufacturer Intel
- Total Drives Supported 2
- Dimensions 399 mm Depth
- Dimensions 43 mm Height
- Dimensions 437 mm Width
- Manufacturer Supermicro
- Motherboard Model X14
- Product Model SYS-112D-40C-FN8P
- DIMM Type RDIMM
